Spin transition

When to use

Use when a cut should carry energy and change axis after straight wipes: the camera rolls 90 degrees. Shot A rolls from 0 to 45 degrees, speeding up, the cut lands at full speed, and shot B rolls from -45 to 0 and lands soft. Two details sell it. The frame scales up by exactly as much as each angle needs to keep covering the frame (2.0x at 45 degrees for 16:9), so no corner of the ground ever shows. And the blur is rotational: 16 copies of the frame at angles fanned across half of one frame's turn, stacked at opacities 1, 1/2, 1/3 and so on, so the edges streak in arcs and the centre stays sharp. Clip: spin-transition.mp4. Demo: demo/spin-transition.html.

The code

import '../../core/engine/page-api.js';
import { easeFn } from '../../core/motion/presets.js';
const W = innerWidth, H = innerHeight, N = 16, clamp = (u) => Math.min(1, Math.max(0, u));
const T0 = 0.45, DUR = 0.5, ROLL = 90;
const whip = easeFn('swap');   // full speed at the cut
const P = (t) => whip(clamp((t - T0) / DUR));
const cover = (deg) => {                                  // the smallest scale at which the turned frame still covers the frame
  const r = Math.abs(deg) * Math.PI / 180, c = Math.cos(r), s = Math.sin(r);
  return Math.max((W * c + H * s) / W, (W * s + H * c) / H);
};
vawe.onFrame((t) => {
  const p = P(t), spread = 0.5 * (P(t + 1 / 60) - p);   // a 180 degree shutter
  const moving = spread * ROLL * (Math.PI / 180) * (W / 2) > 0.5;
  layers.forEach((l, j) => {                            // layer j: opacity 1 / (j + 1), holds a copy of shot A and of shot B
    l.el.style.visibility = j === 0 || moving ? 'visible' : 'hidden';
    const pj = clamp(p + (j / (N - 1) - 0.5) * spread), inB = pj >= 0.5;
    const deg = ROLL * pj - (inB ? ROLL : 0);
    l.a.style.display = inB ? 'none' : 'block';
    l.b.style.display = inB ? 'block' : 'none';
    l.el.style.transform = `rotate(${deg}deg) scale(${cover(deg)})`;
  });
});

Easing and timing

The clip runs 1.4 s. The look is paper.

The clip uses one named ease from core/motion/presets.js. Each is a pair of After Effects handles: influence is how far along the segment the handle reaches, and speed is how fast the value moves at the key, as a multiple of the segment's average speed. Motion in the docs explains both.

Notes

Show one copy when the frame is still. Stacked translucent copies that are rotated fall on Chromium's 256 px compositor tiles, and on a flat light ground the tile seams show as a faint vertical band. Each copy picks its own shot by its own time, so copies either side of the cut mix A and B, which is what a real shutter records. A 0.5 s roll reads as a spin; under 0.35 s it is a flash of blur. Roll the other way at the next spin, and keep type away from the frame corners: they travel the farthest and blur the most.

Looks (ground, type, radius, accent) live in demo/demo.css; this snippet keeps neutral tokens.

Sound

Sound: none; the roll is the seam, and the film keeps its one whoosh for a whip.
